Bently Nevada 330500-08-02 ATEX Sensor: Technical Mastery
ATEX-certified (-02 suffix) for European hazardous zones, this industrial sensor (330500-08-02)features 1/2-13 UNC threads (-08) for rugged installations. Measures 50 in/s peak velocity with ±5% accuracy across -40°C to +100°C (Ta range per ATEX). The 316L stainless steel housing withstands 5,000g shocks and 100% humidity, while maintaining 0.004mm/s ultra-low noise precision. Certified for Zone 1/2 gas environments (Ex ia IIC T4) and compatible with 1,000ft cables (P/N 02173006). Ideal for chemical processing, offshore platforms, and explosive dust areas under EU Directive 2014/34/EU.
Model DNA
-08
1/2-13 UNC Thread
Torque: 24-40 in-lb
-02
ATEX II 2G Ex ia IIC T4
Ta: -40°C to 100°C
Deep Technicals
Electrical Core
• Output: 100mV/in/s ±5%
• Bias: -12VDC ±3V
• Noise: 160μin/s RMS
Mechanical Edge
• Resonance: >12kHz
• Weight: 5.0 oz
• Thread Depth: 0.995″
Environmental Guard
• Humidity: 100% non-condensing
• Base Strain: 0.005 in/s/mstrain
• Magnetic Field: <51μin/s/gauss
Cable Specs
• Max Length: 1,000ft
• Capacitance: 200pF/m
• Part No: 02173006
Certification Matrix
▸ ATEX Directive 2014/34/EU
▸ IECEx IEC 60079-0/11
▸ Installation per DWG-167537
▸ Marine Class: DNV GL-OS-E301
