330191-00-08-90-CN 3300 XL 8 mm ETR Probe Bently Nevada Without Armor

Bently Nevada Long-Range Industrial Probe

Overview

The 330191-00-08-90-CN monitors large machinery with a 9.0m (29.5ft) cable, meeting country-specific safety standards. Built for extreme environments (-55°C to +232°C), it features a stainless steel body and PPS plastic tip. Optional FluidLoc prevents fluid leaks, ideal for power plants and chemical facilities.

Technical Specifications

• Brand: Bently Nevada
• Model: 330191-00-08-90-CN
• Model Suffix Guide:
  • 330191 ➤ Base product code
  • -00 ➤ Standard approvals
    • This variant: -CN = Local compliance
  • -08 ➤ Compact design
    • Case: 0.8″ long (20.3mm)
    • Thread: 3/8-24 UNF
  • -90 ➤ 9.0m cable length
• Electrical Data:
  • Voltage: -17.5VDC to -26VDC (±0.5V)
  • Resistance: 9.87Ω ±0.50 @25°C
  • Current: 12mA (18mA with barriers)
• Mechanical Strength:
  • Cable pull: 75lbs (330N) tested
  • Thread torque: 5in·lbf (0.565N·m)
  • Weight: 11.4oz/ft (323g/m)

Certifications

• Complies with local industrial regulations
• ATEX/IECEx EPL Gc/Dc
• NACE MR0103 material standard
