330140-08-90-11-05 | Bently Nevada 3300 XL 8 mm Probe Without Armor

Bently Nevada 330140-08-90-11-05: Explosion-Proof Sensor with FluidLock

Model Code Translation

330140-08-90-11-05 deciphers as:
• 11 = FluidLoc + ClickLoc protector
• 05 = ATEX/IECEx/CSA certified
• 08 = 0.8″ (20mm) case
• 90 = 29.5ft cable

3 Critical Upgrades

1. LeakLock™ Tech – Blocks oil ingress at 7psi pressure
2. Ex-Proof Certified – IECEx T4 rating for Zone 2
3. Armored Tip – 8mm PPS shield (40% thicker)

Hazardous Area Ready

• ATEX Cat 3G/3D approved
• CSA Class I Div 2 compliant
• IECEx Ex ia IIC T4 Ga
• Meets API 670 ed.5 standards

Extreme Performance

► Temp Range: -62°F to +500°F (cable)
► Pull Strength: 330N (75lbs) retention
► Humidity: <3% drift @93% RH/56 days
► Accuracy: ±0.038mm (±1.5mil)

Precision Engineering

• 9.87Ω ±0.5Ω DC resistance
• 7.87V/mm ±6.5% output
• 0.25mm measurement increments
• Viton® seals handle 260°F fluids

Industrial Construction

Body: 304 stainless steel
Cable: 323g/m flexible armor
Installation: Tool-free ClickLoc
Warranty: 12-month coverage

Why Choose 11-05?

This dual-certified probe combines fluid sealing with explosion safety. The 11-05 suffix delivers 0.02mm repeatability in refinery/petrochemical applications. Includes U.S. origin documentation.
