330104-03-12-50-02-05 | 3300 XL 8mm Proximity Probe – With Armor

Bently Nevada 330104-03-12-50-02-05 3300 XL 8 mm Proximity Probe

Complete Model Structure

• Product Number: 330104-03-12-50-02-05
• Probe Type: 3300 XL 8 mm Proximity Probe
• Thread: M10 x 1 with armor
• Unthreaded Length: 30 mm
• Overall Case Length: 120 mm
• Total Cable Length: 5.0 meters (16.4 feet)
• Connector & Cable: Miniature coaxial ClickLoc connector, standard cable
• Agency Approvals: CSA, ATEX, IECEx

Technical Parameters

• Range and Sensitivity: Linear range 2 mm (80 mils), starts at 0.25 mm (10 mils)
• Recommended Gap: 1.27 mm (50 mils), output around -9 Vdc
• Resistance: Nominal DC resistance 8.73 ± 0.50 Ω at 5.0 m length
• Output Signal: Compatible with 3300 XL Proximitor sensor only
• Max Thread Engagement: 15 mm
• Weight: 323 grams per meter (11.4 oz)

Operating Conditions

• Temperature Range: Standard -52°C to +177°C (-62°F to +350°F)
• Extended Range: Probe tip up to +218°C (+425°F), cable and connector up to +260°C (+500°F)
• Humidity: Less than 3% change in output after 56 days at 93% humidity
• Pressure Seal: Viton® O-ring seal between probe tip and case

Compatibility and Safety

• Certified for Class I, Zone 0 & 2 hazardous areas when installed with appropriate barriers
• Meets CSA, ATEX, IECEx standards
• Supports intrinsic safety with zener barriers or galvanic isolators
