330104-00-07-10-01-CN | 3300 XL 8mm Proximity Probe – With Armor

Bently Nevada 330104-00-07-10-01-CN Proximity Probe

Model Breakdown

• 330104: 3300 XL 8 mm Probe
• 00: 0 mm Unthreaded Length
• 07: 70 mm Case Length
• 10: 1.0 m Cable
• 01: Mini ClickLoc Connector with Protector
• CN: Country-Specific Approval

Technical Specifications

• Measurement Range: 0.25 mm to 2.3 mm
• Linear Range: 2 mm
• System Accuracy: ±0.07 mm with AISI 4140 target
• Probe Resistance: 7.59 ± 0.50 Ohms (1.0 m length)
• Output Resistance: 50 Ohms
• Sensitivity: Less than 2 mV change per volt input
• Working Voltage: -17.5 VDC to -26 VDC
• Power Draw: Max 12 mA
• Operating Temperature: +18°C to +27°C
• Altitude Limit: 2000 meters

Materials

• Tip Material: Polyphenylene Sulfide (PPS)
• Case Material: AISI 303 or 304 Stainless Steel
• Seal Type: Viton O-ring (pressure sealed)

Installation Guide

• Connect only with 3300 XL 8 mm Extension Cable
• Use in clean, dry locations
• Do not install in areas above 2000 m without special setup
• Secure using M10 x 1 thread configuration

Compatibility

• Works with 3300 XL Proximitor Sensor
• For use with extension cables up to 5 meters
• Use with AISI 4140 steel target for best results

Package Includes

• 1x 330104-00-07-10-01-CN Probe
• Armor-protected cable
• Connector with protector
• 12-month warranty
