Bently Nevada 330104-00-22-10-02-CN 3300 XL 8 mm Proximity Probe
Product Overview
The Bently Nevada 330104-00-22-10-02-CN is a high-performance 8 mm proximity probe designed for precise non-contact vibration and position measurement in industrial equipment. This model features a durable armored cable, M10 x 1 threaded body, and a 1.0 meter cable length with a standard miniature ClickLoc connector.
Key Technical Specifications
- Measurement Range: Up to 2 mm (80 mils)
- Accuracy: System calibrated with AISI 4140 steel target
- Output Signal: Voltage proportional to distance
- Power Supply: -17.5 Vdc to -26 Vdc (12 mA max)
- Output Resistance: 50 Ohms
- Operating Temperature: +18°C to +27°C
- Probe Resistance: 7.59 ± 0.50 Ohms
- Pressure Rating: Suitable for differential pressure sealing
Materials
- Probe Tip: Polyphenylene sulfide (PPS)
- Probe Case: AISI 303 or 304 Stainless Steel
- Seal: Viton O-ring
Complete Model Breakdown
- 330104: 3300 XL 8 mm Probe
- 00: 0 mm unthreaded length
- 22: 220 mm overall case length
- 10: 1.0 meter cable length
- 02: Miniature coaxial ClickLoc connector, standard cable
- CN: Country-Specific Approval
Installation Guide
- Thread size: M10 x 1
- Recommended gap: 1.27 mm (50 mils)
- Target Material: AISI 4140 Steel
- Mount with appropriate locking mechanism to secure probe
Compatibility
- Fully compatible with 3300 XL Extension Cables
- Designed to work with 3300 XL Proximitor Sensors
Packaging Contents
- 1 x 330104-00-22-10-02-CN Proximity Probe
- 1 x Armored cable (pre-installed)
- 1 x Installation instruction sheet
