Bently Nevada 330910-00-18-70-02-00 Proximity Probe
Product Overview
This probe is from the 3300 NSv series. It is made for small machines and tight spaces. It includes a 180 mm case and a 7-meter cable. The cable has a ClickLoc connector for fast setup. Use it to measure vibration in key machines.
Key Features
- Thread Type: M10x1 with armor
- Unthreaded Tip: 00 mm
- Case Length: 180 mm
- Total Cable Length: 7 meters (23 feet)
- Connector: ClickLoc, standard coaxial cable
- DC Resistance: 5.9 ± 0.9 ohms
- Cable Impedance: 75 ohms
- Cable Cover: FEP insulation
Material Details
- Probe Tip: PPS plastic
- Case: Stainless steel (304 SST)
- Weight: 14 to 150 grams
- Min. Bend Radius: 25.4 mm
- Max Thread Length: 15 mm
Torque Ratings
- Case Max Torque: 33.9 N·m
- Case Tightening: 11.3 N·m
- Connector Max: 0.56 N·m (finger-tight)
Model Breakdown (330910-00-18-70-02-00)
- 330910 – NSv probe type
- 00 – No unthreaded section
- 18 – Case length 180 mm
- 70 – 7-meter cable
- 02 – ClickLoc connector, standard cable
- 00 – No agency approval
Shipping and Warranty
- Ships via FedEx, UPS, or DHL
- 12-month factory warranty included
