3300 NSv Proximity Probes Metric 330910-03-20-10-11-00 Bently Nevada

Bently Nevada 330910-03-20-10-11-00 | 3300 NSv Proximity Probe

Product Overview

The Bently Nevada 330910-03-20-10-11-00 is a 3300 NSv series proximity probe. It is ideal for applications with tight installation spaces and where high-accuracy shaft vibration or position measurements are needed. This model features an armored cable, fluid-resistant insulation, and rugged design suitable for harsh environments.

Technical Specifications

• Thread Type: M10x1
• Unthreaded Length: 30 mm
• Case Length: 200 mm
• Total Cable Length: 1.0 meter (39 inches)
• Connector Type: Miniature coaxial ClickLoc with protector
• Cable Type: FluidLoc, 75-ohm FEP insulated coaxial
• DC Resistance: 4.2 ± 0.5 ohms at 1.0 meter
• Weight: Approximately 14 to 150 g

Environmental Ratings

• Operating Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C
• Minimum Bend Radius: 25.4 mm

Temperature Ratings for Application Zones

• T1: -55°C to +232°C
• T2: -55°C to +177°C
• T3: -55°C to +120°C
• T4: -55°C to +80°C
• T5: -55°C to +40°C

Ordering Code Structure

• 330910 = NSv Probe
• -03 = 30 mm unthreaded length
• -20 = 200 mm case length
• -10 = 1.0 meter total cable length
• -11 = ClickLoc connector with protector
• -00 = No agency approvals

Installation Guide

• Ensure probe is mounted finger-tight only
• Maintain a thread engagement of up to 15 mm for M10x1
• Avoid bending cable below 25.4 mm radius
• Use only recommended torque during installation
