3300 NSv Proximity Probes Metric 330910-00-03-50-02-00 Bently Nevada

Bently Nevada 330910-00-03-50-02-00 Proximity Probe

Overview

The Bently Nevada 330910-00-03-50-02-00 is a high-precision 3300 NSv Proximity Probe with M10x1 thread and stainless steel armor. Designed for harsh industrial environments, it is ideal for small machines where space is tight and vibration monitoring is essential.

Key Technical Specifications

• Thread: M10x1 with stainless steel armor
• Unthreaded Length: 0 mm
• Overall Case Length: 30 mm
• Total Probe Length: 5.0 meters (16.4 feet)
• Connector: Miniature coaxial ClickLoc
• Probe Tip: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Cable Type: 75 Ohm coaxial, FEP insulated
• Minimum Bend Radius: 25.4 mm (1.0 in)
• Weight: Approx. 14 to 150 g

Additional Performance Data

• DC Resistance (5.0 m): 5.3 ± 0.7 Ohms
• Thread Engagement Limit: 15 mm
• Case Torque: Max 33.9 Nm, Recommended 11.3 Nm
• Connector Torque: Max 0.56 Nm, Finger-tight recommended

Model Tree – Full Ordering Breakdown

• 330910 – NSv Probe, M10x1 thread, with stainless steel armor
  • 00 – Unthreaded Length: 0 mm
  • 03 – Case Length: 30 mm
  • 50 – Total Length: 5.0 meters
  • 02 – Miniature coaxial ClickLoc connector, standard cable
  • 00 – No agency approvals required

Warranty and Shipping

• Warranty: 12 months manufacturer warranty
• Shipping: Global express via FedEx, UPS, DHL
