Bently Nevada 330901-00-90-10-01-05 3300 NSv Proximity Probe
Product Overview
The Bently Nevada 330901-00-90-10-01-05 is a high-performance 3300 NSv proximity probe. It uses a 1/4-28 UNF thread and has no armor, making it suitable for space-constrained industrial areas.
Key Technical Parameters
- Thread Type: 1/4-28 UNF
- Unthreaded Length: 0.0 inch
- Overall Case Length: 9.0 inches
- Total Probe Length: 1.0 meter
- Connector Type: Miniature coaxial ClickLoc with protector
- Cable Type: Standard cable, 75 Ω coaxial, FEP insulated
- Temperature Range: -52°C to +177°C (Operating and Storage)
- Case Material: AISI304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- DC Resistance (1.0 m): 4.2 ± 0.5 ohms
- Recommended Mounting Torque: 5.1 N·m (45 in·lb)
- Max Thread Engagement: 0.375 inch
- Seal Type: Viton O-ring (differential pressure seal)
- Weight: Approximately 14 to 150 g
Extended Technical Range Options
- Available in total lengths: 0.5 m, 1 m, 5 m, and 7 m
- Supports environments down to -40°C in dry installations
- Tested for tight enclosure fits up to 0.35 in depth
- Withstands minor fluid exposure thanks to FEP jacket
Model Suffix Tree
- 330901: 3300 NSv Probe, 1/4-28 UNF thread, without armor
- -00: 0.0 in unthreaded length
- -90: 9.0 in overall case length
- -10: 1.0 meter total length
- -01: Miniature coaxial ClickLoc with protector, standard cable
- -05: Multiple agency approvals
