22D-D024N104 | Allen-Bradley PowerFlex 40P AC Drive

Allen-Bradley 22D-D024N104 PowerFlex Drive – 15HP Industrial Motor Controller

High-Power Precision Control for Demanding Applications

The 22D-D024N104 delivers 15HP (11kW) of reliable motor control with advanced networking capabilities. Perfect for industrial automation, this panel-mount drive works with 380-480V 3-phase systems.

Technical Specifications

• Model: 22D-D024N104
• Power: 15HP (11kW)
• Input Voltage: 380-480V AC 3-phase
• Output Current: 24A
• Frequency Range: 0-500Hz programmable
• Frame: Size C
• Dimensions: 260×130×180mm (10.2×5.1×7.1in)
• Weight: 6.5kg
• Temp Range: -10°C to 50°C (14°F to 122°F)
• Communication: RS485 + optional expansion cards

Package & Support

• 12-month product warranty
• Fast global shipping (FedEx/UPS/DHL)
• Includes mounting hardware

Expert Answers

• What’s Zero Stacking?
  Allows mounting drives side-by-side to save space
• Can I add Ethernet connectivity?
  Yes, with optional EtherNet/IP card
• How many preset speeds can I program?
  Up to 5 preset speeds available
• Does it need special cooling?
  No, convection cooling is sufficient
• Can it handle voltage fluctuations?
  Yes, works from 342-528V AC input
