Allen-Bradley 1769-OB16: High-Speed 16-Channel DC Output Module

Key Features

The 1769-OB16 delivers 16 fast-switching DC outputs in one compact module. With ultra-fast 0.1ms response, it’s perfect for precision control of relays, solenoids, and indicators in automated systems.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1769-OB16 (Current Production)
• Output Type: 24V DC sourcing
• Channels: 16 (single group)
• Voltage Range: 20.4-26.4V DC
• Current Capacity: 1A per point @30°C
• Response Time: 0.1ms ON / 1ms OFF
• Surge Current: 2A for 10ms
• Dimensions: 4.65″ x 1.38″ x 3.43″
• Weight: 0.61 lbs (280g)

Easy Installation

Includes 1769-RTBN18 terminal block. Use 22-14 AWG copper wire. Mounts on DIN rail or panel with M4 screws.

System Compatibility

Works with CompactLogix and MicroLogix 1500 controllers. IEC Class 2 certified.

Package Contents

• 1769-OB16 module
• Terminal block
• Installation guide

Reliability Promise

12-month performance guarantee. Ships worldwide via FedEx, UPS, or DHL.

Expert FAQs

• Q: Can it control AC devices?
  A: Yes, when used with interposing relays
• Q: What’s the minimum load current?
  A: 1mA maintains reliable operation
• Q: How many modules per power supply?
  A> Maximum 8-module distance rating
• Q: Is it suitable for PWM applications?
  A: Yes, with 0.1ms fast switching
• Q: What wire types are supported?
  A: 22-14 AWG solid or 22-16 AWG stranded

Get Documentation

• Complete product manual: Download 1769-OB16 Specs
• Wiring examples: Get Connection Guide
